Dock Seals
The Dock Seals superior 36 oz. nylon reinforced vinyl facings have a higher tear strength than equivalent weight Hypalon
The chemically sealed ends prevent moisture infiltration. It is mounted on and bonded to a durable womanized wood and contains a full height air escape tunnel. The unit consists of a three (3) piece construction (12" high; sides - beveled sides with 9-1/2" width at the wall and 12" width at the face) and a through the wall installation kit that is included. 5" maximum compression is recommended. Application with a flush dock to building in conjunction with an Edge-O-Dock use a twenty (20) inch projection Dock Seal. To ensure proper size complete and fax the survey sheet below. Units are non-returnable.
| Model | * | Net Wt. (lbs.) |
|
|---|---|---|---|
| D-150-10 | DOCK SEAL 10 IN PROJECTION 8X8 DOOR | Projection (in.):10 | 212 |
| D-150-11 | DOCK SEAL 11 IN PROJECTION 8X8 DOOR | Projection (in.):11 | 214 |
| D-150-12 | DOCK SEAL 12 IN PROJECTION 8X8 DOOR | Projection (in.):12 | 216 |
| D-150-13 | DOCK SEAL 13 IN PROJECTION 8X8 DOOR | Projection (in.):13 | 218 |
| D-150-14 | DOCK SEAL 14 IN PROJECTION 8X8 DOOR | Projection (in.):14 | 219 |
| D-150-15 | DOCK SEAL 15 IN PROJECTION 8X8 DOOR | Projection (in.):15 | 220 |
| D-150-16 | DOCK SEAL 16 IN PROJECTION 8X8 DOOR | Projection (in.):16 | 221 |
| D-150-17 | DOCK SEAL 17 IN PROJECTION 8X8 DOOR | Projection (in.):17 | 222 |
| D-150-18 | DOCK SEAL 18 IN PROJECTION 8X8 DOOR | Projection (in.):18 | 249 |
| D-150-19 | DOCK SEAL 19 IN PROJECTION 8X8 DOOR | Projection (in.):19 | 251 |
| D-150-20 | DOCK SEAL 20 IN PROJECTION 8X8 DOOR | Projection (in.):20 | 252 |
| D-350-10 | DOCK SEAL 10 IN PROJECTION 8X9 DOOR | Projection (in.):10 | 216 |
| D-350-11 | DOCK SEAL 11 IN PROJECTION 8X9 DOOR | Projection (in.):11 | 218 |
| D-350-12 | DOCK SEAL 12 IN PROJECTION 8X9 DOOR | Projection (in.):12 | 221 |
| D-350-13 | DOCK SEAL 13 IN PROJECTION 8X9 DOOR | Projection (in.):13 | 225 |
| D-350-14 | DOCK SEAL 14 IN PROJECTION 8X9 DOOR | Projection (in.):14 | 237 |
| D-350-15 | DOCK SEAL 15 IN PROJECTION 8X9 DOOR | Projection (in.):15 | 243 |
| D-350-16 | DOCK SEAL 16 IN PROJECTION 8X9 DOOR | Projection (in.):16 | 248 |
| D-350-17 | DOCK SEAL 17 IN PROJECTION 8X9 DOOR | Projection (in.):17 | 250 |
| D-350-18 | DOCK SEAL 18 IN PROJECTION 8X9 DOOR | Projection (in.):18 | 264 |
| D-350-19 | DOCK SEAL 19 IN PROJECTION 8X9 DOOR | Projection (in.):19 | 270 |
| D-350-20 | DOCK SEAL 20 IN PROJECTION 8X9 DOOR | Projection (in.):20 | 275 |
Original: $1,008.33
-65%$1,008.33
$352.92Product Information
