1-Ton Electric Chain Hoist 1-Phase 20' Lift | BLVS100-020
JET Trademaster® Series Electric Hoists combines safety, portability, and durability to operate in all your industrial, construction, and transportation applications.
With its market leading wireless controller and 2 in 1 mechanical brake and overload slip clutch, safety is most important. With the only DC Brushless motor in the market, 5 pocket chain sheave, and thermal overload protection, you have the durability you need to reduce maintenance costs. All of this with a lightweight compact housing that will get you into those tight areas while allowing you transport it from job to job in its molded carrying case. The Tradesmaster® Series comes in 1/8-Ton to 2-Ton capacities and standard lifts of 10 and 20ft (custom lifts up to 100ft are available).
Features
Specifications
| Stock Number | 104035 |
|---|---|
| Capacity (Lbs.) | 2200 |
| Duty Cycle (%) | 30 |
| Duty Cycle Rating | H3 |
| Lift (Ft.) | 20 |
| Lifting Speed (FPM) | 0 -4 / 18 |
| Load Capacity (Tons) | 1 |
| Max. Number of Starts (Per Hr.) | 180 |
| Max. On Time (Min. / Hr.) | 30/7.5 |
| Motor (HP) | 1.33HP, 110V 60Hz |
| Motor Phase | Single |
| Overload Protection | Yes |
| Prop 65 | Cancer |
| Weight (Lbs.) | 128 |
| Headroom (In.) | 20-3/4 |
| Overall Width (In.) | 15-3/10 |
| Motor Current (Amps) | 15 |
| Headroom (in.) | 20-3/4 |
Original: $8,414.00
-65%$8,414.00
$2,944.90Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
JET Trademaster® Series Electric Hoists combines safety, portability, and durability to operate in all your industrial, construction, and transportation applications.
With its market leading wireless controller and 2 in 1 mechanical brake and overload slip clutch, safety is most important. With the only DC Brushless motor in the market, 5 pocket chain sheave, and thermal overload protection, you have the durability you need to reduce maintenance costs. All of this with a lightweight compact housing that will get you into those tight areas while allowing you transport it from job to job in its molded carrying case. The Tradesmaster® Series comes in 1/8-Ton to 2-Ton capacities and standard lifts of 10 and 20ft (custom lifts up to 100ft are available).
Features
Specifications
| Stock Number | 104035 |
|---|---|
| Capacity (Lbs.) | 2200 |
| Duty Cycle (%) | 30 |
| Duty Cycle Rating | H3 |
| Lift (Ft.) | 20 |
| Lifting Speed (FPM) | 0 -4 / 18 |
| Load Capacity (Tons) | 1 |
| Max. Number of Starts (Per Hr.) | 180 |
| Max. On Time (Min. / Hr.) | 30/7.5 |
| Motor (HP) | 1.33HP, 110V 60Hz |
| Motor Phase | Single |
| Overload Protection | Yes |
| Prop 65 | Cancer |
| Weight (Lbs.) | 128 |
| Headroom (In.) | 20-3/4 |
| Overall Width (In.) | 15-3/10 |
| Motor Current (Amps) | 15 |
| Headroom (in.) | 20-3/4 |
