The Bartell BR3570 is versatile, affordable, and packs a punch! Perfect for many general compaction needs, pounding larger footprints quickly and effectively.

The fully hydraulic reversing mechanism sets the Bartell line of reversible compactors apart from the competition, providing more flexible maneuverability for forward, backward, and spot-on compaction.

• Cast aluminum throttle lever for professional and durable control
• Integrated lifting bale for safe loading and unloading
• Full roll cage and cast aluminum belt cover for clutch and engine protection
• Ductile iron bases for increased strength
• Retractable wheels flip down for built-in mobility
• Optional extension plates further increase production rates
• Full speed in both forwards and reverse
• Specialized for compacting sand, trench, and patching



Spec Sheet

Engine Type	Honda GX270
Power Output	8.5hp (6.3kW)
Compaction Force	7871 lbf, 35 kN, 3570 kgf
Max Travel Speed	52'/min (16m/min)
Length	53" (134cm)
Width	18" (45cm)
Height	38" (96cm)
Weight	449 lbs (204kg)
Plate Size	18" x 28" (45cm x 70cm)
