Bartell Global's HD series dust extractors feature a two-stage filtering system with jet-pulse filter cleaning. Remove up to 99.97% of dangerous airborne particulates to keep your operators safe and your business compliant with environmental regulations.
- Two-stage filtering system comprised of one main conical filter, plus 1 HEPA filter
- Reverse-air jet-pulse filter cleaning system effectively cleans and removes dust build-up on the filters
- Easy to use inlet closure eliminates the need to remove hoses when pulsing and cleaning filters
- Easily connects to hand-operated power tools to extract concrete dust while cutting and grinding
- Equipped with a continuous-bag system for safe & easy disposal of concrete dust
- Comes with 15ft hose and floor wand
Technical Specs
| Models | HD1 |
|---|---|
| Volts | 120 |
| Amps | 8 |
| Inlet Diameter | 2.5" (63mm) |
| Power (hp) | 1.6hp |
| Air Flow (cfm) | 120 |
| Water lift (inches) | 100 |
| Pre-filter (F8) >99.5% @1.0um | 16 ft2 (1.5m2) |
| HEPA Filter (H13) >99.99% @0.3um | 13 ft2 |
| Length | 26" (65cm) |
| Width | 16.5" (42cm) |
| Height | 42" (107cm) |
| Weight | 77 lbs (35kg) |
