Husqvarna DM 430
DM 430 is a powerful and sturdy electric core drill for medium to heavy core drilling where reliability and high productivity are needed, especially with large diameter core bits.
Recommended diameter 100-450 mm. With an aluminum motor housing to withstand tough handling and a carrying handle for ergonomic usage and additional impact protection of the drill motor. Equipped with Embedded Connectivity, an enhanced version of Husqvarna Fleet Services™ for data analytics and insights into the health of the machine. Suitable for water evacuation, ventilation, angle drilling, stitch drilling, and when you need to cut close to corners.
Specifications
| Specification | Details |
|---|---|
| Rated Input Power | 4.29 hp |
| Weight | 34.2 lbs |
| Drill Bit Diameter (with stand, max) | 18 in |
| Recommended Drill Bit Diameter (min) | 4 in |
Feature Overview
- Sturdy and durable
- Ergonomic
- Optimized RPMs
- Embedded Connectivity
- Quick connection
- Quick-release washer
- Functional design
- Load indicator
- Elgard™
- Reliable gearbox
- Easy start with reduced speed
- Angle drilling
- Barriers
- Horizontal drilling
- Stitch drilling
- Vertical drilling
- Water evacuation
|
Rated input power
|
4.29 hp
|
|
Frequency
|
50-60 Hz
|
|
Voltage
|
100-120 V
|
|
Phases
|
1 ph
|
|
Power source
|
Corded
|
|
Equipment
|
|
|
Drill bit diameter with stand, max
|
18 in
|
|
Recommended drill bit diameter, min
|
4 in
|
|
Coolant
|
Wet
|
|
Transmission
|
|
|
Number of gearbox speeds
|
3
|
|
Spindle speed unloaded gear 1
|
250 rpm
|
|
Spindle speed unloaded gear 2
|
510 rpm
|
|
Spindle speed unloaded gear 3
|
800 rpm
|
|
Product data
|
|
|
Water connector
|
G 1 / 4"
|
|
Water pressure, max
|
43.5 psi
|
|
Spindle thread, outer
|
1 1/4" 7 UNC
|
|
Dimensions
|
|
|
Product size length
|
23 in
|
|
Product size width
|
5.5 in
|
|
Product size height
|
7.3 in
|
|
Weight
|
34.2 lbs
|
|
Packaging length (Calc)
|
26.181 in
|
|
Packaging width (Calc)
|
10.039 in
|
|
Packaging height (Calc)
|
11.811 in
|
|
Article gross weight (Calc)
|
38.581 lbs
|
|
Sound and noise
|
|
|
Sound power level, guaranteed (LWA)
|
112 dB(A)
|
|
Sound power level, measured
|
110 dB(A)
|
|
Sound pressure level at operators ear (LpA)
|
92 dB(A)
|
